MSI GeForce RTX 5070 Ti features 16GB GDDR7 memory and PCIe 5.0 interface for high-speed gaming.
Quick Specifications
Manufacturer Specifications
| Marketing Name | GeForce RTX™ 5070 Ti 16G SHADOW 3X OC |
| Model Name | G507T-16S3C |
| Graphics Processing Unit | NVIDIA® GeForce RTX™ 5070 Ti |
| Interface | PCI Express® Gen 5 |
| Core Clocks | Extreme Performance: 2497 MHz (MSI Center) |
| Boost: 2482 MHz | |
| CUDA® CORES | 8960 Units |
| Memory Speed | 28 Gbps |
| Memory | 16GB GDDR7 |
| Memory Bus | 256-bit |
| Output | DisplayPort x 3 (v2.1b) |
| HDMI™ x 1 (As specified in HDMI™ 2.1b: up to 4K 480Hz or 8K 120Hz with DSC, Gaming VRR, HDR) | |
| HDCP Support | Y |
| Power consumption | 300 W |
| Power connectors | 16-pin x 1 |
| Recommended PSU | 750 W |
| Card Dimension (mm) | 303 x 121 x 49 mm |
| Weight (Card / Package) | 994 g / 1474 g |
| DirectX Version Support | 12 Ultimate |
| OpenGL Version Support | 4.6 |
| Maximum Displays | 4 |
| G-SYNC® technology | Y |
| Digital Maximum Resolution |
7680 x 4320 |
